New cFos Analyzer
Our finest measuring instrument

How fast is your Internet connection? Does it deliver what your provider promises? Are there bottlenecks at certain times of day? How responsive is your Internet? How high is your ping?

Download cFos Analyzer V0.90, build 2101 Coming on December 1, 2026 Beta

Measures in the background, without getting in the way

Conventional speed tests saturate your connection and use lots of data in both directions, upload and download.

cFos Analyzer measures mostly passively and uses almost no data. That is why it does not disturb your Internet use.

No central server needed

Another big advantage: cFos Analyzer does not need a central server at the other end. It measures certain properties against your provider's exchange, everything else by passive observation and occasional small extra measurements.

At the start, cFos Analyzer determines which network adapter you have and how it passes network packets on to Windows. We also measure the behaviour of your access concentrator, the counterpart of your DSL or fibre modem, and of further "hops" on the way into the public Internet. Measurement pulses (e.g. pings) stay limited to the first hops.

Measurement

In principle we measure the interpacket delay, i.e. the gap that appears between two consecutive data packets when they are sent or received. We assume that packets travel through the Internet at "infinite" speed and are slowed down to your actual connection speed just before your router. The resulting gap is proportional to the upload or download speed.

The measured speed refers to pure IP traffic (IP frames without Ethernet, PPPoE or other overhead) in Mbit/s.

Fibre and TV cable connections pose a problem: the first few kilobytes arrive much faster than the connection speed, i.e. the access concentrator only starts to throttle after a short time. We can measure such connections when your application almost fills the channel. Then cFos Analyzer can generate small amounts of extra data to measure the actual speed.

Latency (RTT)

cFos Analyzer also measures the "round trip time" to your access concentrator, i.e. to the next node outside your home. This tells it the minimum latency your connection has by design. If the latency rises, the cause is a queue on your side or an overloaded connection. This can happen, for example, when someone else in your household is using your Internet connection to the full.

Preliminary and confirmed values

Because of this measuring principle, cFos Analyzer waits, depending on how the connection is being used at the moment, until it is sufficiently sure that it has measured the current line speed. Preliminary values appear in brackets; values regarded as confirmed appear on the left of the status window without brackets. As long as you do not use one direction of your connection, or hardly use it, cFos Analyzer cannot measure its speed.

In our tests, though, watching a video for a few seconds is enough to measure the download speed. For upload, depending on the connection, cFos Analyzer can send an optimised measurement pulse to the access concentrator or to one of the next hops, so that it can measure the upload speed without using much data, even when you hardly use the upload direction.

Cost

cFos Analyzer is currently free. We depend on your help and need your anonymised usage data (which packet sizes you send and receive at which intervals, which network adapters you use and on which Internet connection). We use the data to release an improved version of cFos Analyzer every few months. Please enable the transfer of usage data during installation or later in the settings.

OEM partners

We are looking for OEM partners who would like to offer cFos Analyzer to their customers under their own brand and with their own logo. That is why the status window is built in HTML and easy to change to the design you want. Wouldn't that be a nice extra for your users? Inquiries are welcome: through our contact form (topic "OEM Inquiry").

More about our OEM products, licence terms and partners: OEM versions.

Supported technologies

Network
LAN/Ethernet
Wi-Fi
Internet media
DSL
Fibre
Mobile (in preparation)
Operating system
Windows 10 and later

Download

Download cFos Analyzer V0.90, build 2101 Coming on December 1, 2026 Beta
